150 tonne x 100mm stroke hydraulic cylinder

150tonne High quality Hydraulic Cylinder

Model: HHYG-150100

Capacity: 150tonne

Stroke: 100mm

Closed height: 232mm

Extended height: 332mm

Oil capacity: 2237cc

Outside diameter: 205mm

Chrome plated cylinder & ram

Spring return

Maximum pressure: 700 bar

Fitted with Female Coupling

Weight: 53kg

Supplied fully tested with relevant certificate

12month warranty

PLEASE NOTE - YOU WILL NEED TO USE THE HHB-700-3000CC or HHB-700-7000CC HAND PUMP TO OPERATE THIS CYLINDER
